In the world of product testing and verification where requirements such as high accuracy, cryogenic or high temperatures, low and high pressure ranges, as well as high frequency, high amplitude testing exist – highly accurate and reliable pressure measurement are a must. Such are the requirements typically asked of GP:50. So we custom design products with pressure ranges from 0-20” WC thru 0-100,000 PSI, gage, vacuum, absolute and differential formats as well as accuracies to 0.05% FSO and operating ranges from -320 to 375 deg F. In short, GP:50 has a product to meet most every test stand requirement.
| Model: | 241/341 |
| Range: | 0-30” WC thru 8K PSI (552 BAR) *Gauge, Vacuum, Absolute, Sealed Gauge (Both Hermetic & Non-Hermetic) |
| Warranty: | Product Warranty |
Model 241/341 from GP:50 is our most accurate pressure transducer. Designed specifically for aerospace and automotive test stand applications, it is 5x tighter through temperature than standard industrial transmitters with a 0.20% FSO / 100 °F thermal stability. More than 25 years of field expertise went into the design of our pressure transducer for exceptional reliability. The compact, corrosion-resistant, all-welded stainless steel design of the Model 241/341 offers ease of installation within space constrained environments. Static accuracy is available to ±0.05% FSO, with a total thermal error of 0.25% FSO over the compensated temperature range.
Learn More
| Model: | 140/240/340 |
| Range: | 0 to 1 PSI thru 0 to 30K PSI, *Some Options May Affect Range (PSIG, PSIS, PSIA, PSIV & Compound Ranges Available) |
| Warranty: | Product Warranty |
The Model 40 Series provides a compact, rugged design to meet the demands of hydraulic and pneumatic applications found in process
automation, test stand, and OEM applications. Its rugged stainless steel design offers high corrosion resistance in pressure ranges from 0-25” WC (69 Mbar) to 30K PSI (2068 bar).
| Model: | 540 |
| Range: | 0-1 PSI thru 0-10K PSI (3.5 mBAR to 344 BAR) *Gauge, Sealed Gauge, Absolute |
| Warranty: | Product Warranty |
GP:50 model 540 CAN Bus digital output pressure transducer provides high resolution, accuracy, and improved thermal performance to meet the demands of the automotive, medical and laboratory test markets. The CAN Open protocol allows for multiple devices on a single bus reducing installation time and cost.
Learn More
| Model: | 541 |
| Range: | 0 to 1 thru 0 to 10,000 PSI (0.069 thru 690 BAR) *Gauge, Sealed, Absolute |
| Warranty: | Product Warranty |
The Model 541 series is our most accurate CAN based pressure transducer. Designed specifically for test stand applications, the CAN Bus protocol provides high resolution, reduced noise and improved thermal performance. The compact, all-welded stainless steel design of the Model 541 offers ease of installation within space constrained environments. Static accuracy is available to ±0.05% FSO, with a total thermal error of 0.25% FSO over the compensated temperature range.
Learn More
| Range: | 0-50 thru 0-10K PSI (3.5 thru 690 BAR) *Gauge, Sealed Gauge, Absolute |
| Warranty: | Product Warranty |
The Model 543 Series from GP:50 is an all-stainless steel, dual pressure and temperature CAN Bus output transmitter. Its compact design reduces I/O and insertion points where size and weight are considerations. Units are available in a variety of pressure and temperature ranges, with support for both CAN Bus J1939 and CAN Open protocols.
Learn More
| Model: | 741 |
| Range: | 0 to 1 thru 0 to 8,000 PSI (0.069 thru 552 BAR) *Gauge, Sealed Gauge, Absolute |
| Warranty: | Product Warranty |
GP:50 Model 741 provides RS485 digital data transmission used in serial communication protocols standard for Industrial Control Networks and Data Acquisition Systems. High static accuracy, thermal performance and lack of EMI makes the 741 ideal for the auto and aircraft manufacturing floor.
Learn More
| Model: | 136/236/336 |
| Range: | 1 PSID thru 500 PSID (0.1 thru 25 BAR D) *Other Ranges Available |
| Warranty: | Product Warranty |
The Model 136/236/336 from GP:50 is a family of highly accurate, digitally compensated differential pressure transducers. Model 136/236/336 measures differential pressure ranges as low as 20” WCD and line pressures up to 1000 PSID (69 BAR) in a compact size. Customers may also choose from among multiple accuracy, digital output, process and electrical connections. Please consult the factory for details.
Learn More
| Model: | 136/236/336-AI/AF |
| Range: | 1 PSID thru 500 PSID (0.1 thru 25 BAR D) *Other Ranges Available |
| Certification: | ATEX/IEC Intrinsically Safe; ATEX/IEC Flameproof |
| Warranty: | Product Warranty |
The Model 136/236/336-AI/AF from GP:50 is a family of highly accurate, digitally compensated differential pressure transducers. Model 136/236/336-AI/AF measures differential pressure ranges as low as 20” WCD and line pressures up to 1000 PSID (69 BAR) in a compact size. Customers may also choose from among multiple accuracy, digital output, process and electrical connections. Please consult the factory for details.
Learn More
| Model: | 216/316 |
| Range: | 2.5” WCD thru 200 PSID *Alternate Ranges Available |
| Warranty: | Product Warranty |
The Model 216/316 from GP:50 is a family of low range, high line, differential pressure transducers. Their compact design incorporates GP:50’s own digital correction circuit technology, for high accuracy and extended service life across a variety of applications.
Learn More
| Model: | Model 611/612 |
| Range: | • (Model 611) 0 to 1 thru 0 to 15K PSIG (0-0.069 thru 0-1,034 BAR) • (Model 612) 0 to 20k thru 0 to 100K PSIG ( 0-1,379 thru 0-6,895 BAR) |
| Warranty: | Product Warranty |
The Model 611/612 from GP:50 is a USB output pressure transducer. This model features an intuitive and user-friendly interface that allows for
field configuration. For customer convenience, an easy-to-use data acquisition and analysis software is available and fully compatible with
any Windows-based terminal program.
| Model: | 1002/1003 |
| Range: | 0 to 15 thru 0 to 10K PSI (1,034 mBAR thru 689 BAR) *Gauge, Vacuum, and Absolute Pressure Reference Available |
| Warranty: | Product Warranty |
The Model 1002/1003 OEM Industrial Grade Pressure Transmitter from GP:50 is a family of lower cost, industrial grade OEM pressure transducers, featuring corrosion-resistant, all stainless steel wetted parts and housings. Series transducers are ideal for higher volume pressure monitoring applications, particularly where lower costs are required, yet where the need for precision measurement accuracy remains. Units are available with choice of 4-20 mA, 0 to 5 Vdc or 0 to 10 Vdc output, as well as various electrical connection and pressure port options. Typical
applications for the Model 1002/1003 include offroad vehicle, HVAC/R, hydraulic and pneumatic control systems, pumps and compressors, and
industrial engine pressure monitoring.
| Model: | 188/288/388 |
| Range: | 300 PSI to 20K PSI (21 to 1,379 BAR) *Consult Factory For Other Ranges |
| Warranty: | Product Warranty |
Model 188/288/388 from GP:50 is a family of all welded stainless steel miniature flush diaphragm pressure transducers. Their unique design incorporates a specialty flush process connection. This allows the transducer to effectively support higher viscosity fluid pressure measurements without port clogging or plugging. Their compact size allows for ease of installation within space constrained environments.
Learn More
| Model: | 243/343 |
| Range: | 0-50 thru 0-10K PSI (3.5 thru 690 BAR) *Gauge, Sealed Gauge, Absolute |
| Warranty: | Product Warranty |
The Model 243 / 343 Series from GP:50 is an all-stainless steel, dual pressure and temperature transducer with 4-20 mA and 0-5 V output.
Its compact design reduces I/O and insertion points where size and weight are considerations. Units are available in a variety of pressure and
temperature ranges.
| Model: | 111, 211, 311 |
| Range: | 0 to 30" WC thru 0 to 15K PSI (0 to 1,034 BAR) *PSIG, PSIS, PSIA, PSIV & Compound Ranges Available |
| Warranty: | Product Warranty |
The Model 111/211/311 from GP:50 is a family of industrial grade pressure transducers. These strain gauge-based sensors are expressly designed to withstand the shock, vibration and pressure spikes common to most hydraulic and pneumatic control systems.
The highly rugged, all-welded stainless steel design of the Model 111/211/311 offers high corrosion resistance, making the sensors an ideal choice for demanding oil & gas, steelworks, rolling mills and process control applications. Units are further available with optional 10X proof pressure for extended worry-free service life within challenging environments.
Learn More
| Range: | 0 to 100 PSI thru 0 to 15K PSI (0 to 7 BAR thru 0 to 1,034 BAR) |
| Warranty: | Product Warranty |
The Spike Series from GP:50 is a family of pressure transducers, specifically designed to withstand high-amplitude, high-frequency spikes that commonly occur in hydraulic pressure sensing applications. A proprietary sensor design provides increased over pressure protection as high as 10x.
Learn More
| Model: | 240/340 AI/AN/AF |
| Range: | 0 to 1 PSI thru 0 to 50K PSI *Some Options May Affect Range PSIG, PSIS PSIA, PSIV & Compound Ranges Available |
| Certification: | ATEX & IEC Approvals |
| Warranty: | Product Warranty |
Model 40 Series from GP:50 incorporates over 25 years of oil field proven design in a 1” diameter package. The 40 Series provides a rugged solution
for hazardous approved areas, especially where space constraints are a concern. Its all-welded stainless steel design will provide years of reliable
service in some of the harshest environments.
| Model: | 114/214/314 |
| Range: | 500 PSID to 20K PSID (25 BAR D to 1,379 BAR D) |
| Warranty: | Product Warranty |
The Model 114/214/314 from GP:50 is a family of ultra-high range differential pressure transducers. The series offers +0.50% (BFSL) static
accuracy over its standard ranges of 500 to 20K PSID (35 to 1,379 BAR D). Improved accuracy is available to +0.20%. Their rugged, compact design incorporates a unique, non-filled strain gauge sensing technology. These attributes allow the Model 114/214/314 to effectively support high-cycle pressure measurement requirements, even in space constrained environments. An all stainless steel construction, without seals or o-rings, provides high-corrosion resistance. Optional intrinsically safe versions are also available for extreme applications.
| Model: | 142 / 242 / 342 |
| Range: | 0 to 15 thru 0 to 15K PSI (1 thru 1,034 BAR) |
| Warranty: | Product Warranty |
Developed from 20+ years of aerospace experience, the 42 Series was designed with aerospace criteria for industrial applications. The compact all-welded construction offers higher accuracies and a broad thermally compensated range. The 42 Series has all the performance and durability of an aerospace grade unit, but with industrial grade pricing.
Learn More
| Range: | 5" WCD thru 200 PSI, PSIA (14 BAR) |
| Warranty: | Product Warranty |
The GP:50 Model 210/310 series provides a high accuracy, low pressure sensor with high proof pressure. With ranges as low as 0 to 5” WC the standard unit provides proof pressures to 500 PSI with an optional ±0.05% FSO static accuracy.
Learn More
| Range: | 0°F to +250°F (-18°C to +121°C) |
| Warranty: | Product Warranty |
The Model 340T temperature transducer is essential where reliable and accurate process temperatures are required. With a large range of temperature ranges and probe lengths available, the Model 340T is adaptable for most temperature applications or processes. The compact size provides easy installation for on-board vehicles used in the oil and gas industry.
| Model: | 1003T |
| Warranty: | Product Warranty |
The Model 1003T economical temperature transmitter series from GP:50 offers the most common industrycalibrated temperature ranges, process ports, and electrical connection. The 1003T Series provides for better lead times and lower unit cost while delivering a reliable, accurate, temperature measurement.
Learn More
| Model: | 243/343 AI/AN |
| Range: | 0-50 thru 0-10K PSI (3.5 thru 690 BAR) *Gauge, Sealed Gauge, Absolute |
| Certification: | EX, IEC |
| Warranty: | Product Warranty |
The Model 243AI/AN / 343AI/AN Series from GP:50 is an all-stainless steel, dual pressure and temperature transducer with 4-20 mA and 0-5 V output. Its compact design reduces I/O and insertion points where size and weight are considerations. Units are available in a variety of pressure and temperature ranges.
Learn More
| Model: | 1002/1003-CA |
| Range: | 0 to 15 thru 0 to 10K PSI (1,034 mBAR thru 689 BAR), gauge, vacuum, and absolute pressure reference available |
| Certification: | CE |
| Warranty: | Product Warranty |
The Model 1002/1003-CA from GP:50 is a family of lower cost, industrial grade OEM pressure transducers, featuring corrosion-resistant, all
stainless steel wetted parts and housings. Series transducers are ideal for higher volume pressure monitoring applications, particularly where lower
costs are required, yet where the need for precision measurement accuracy remains. Units are available with choice of 4-20 mA, 0 to 5 Vdc or 0 to 10 Vdc output, as well as various electrical connection and pressure port options. Typical applications for the Model 1002/1003-CA include off-road vehicle, HVAC/R, hydraulic and pneumatic control systems, pumps and compressors, and industrial engine pressure monitoring.
| Model: | 111/211/311X/P & 311N/AN/GN |
| Range: | 0 to 5 PSI thru 0 to 75K PSI (75 MBAR to 1,034 BAR) |
| Certification: | FM, CSA, ATEX & IEC Approvals |
| Warranty: | Product Warranty |
GP:50’s Model 11 Series provides a rugged solution in hazardous approved areas. The all welded, stainless steel design provides years of reliable service in some of the harshest applications.
Learn More
| Model: | 340T/AI/AF/AN |
| Range: | 0°F to +250°F (-18°C to +121°C) |
| Certification: | ATEX/IEC Intrinsically Safe, ATEX/IEC Flameproof |
| Warranty: | Product Warranty |
The Model 340T/AI/AF/AN Hazardous Location Temperature Transmitter is essential where reliable and accurate process temperatures are required. With a large range of temperature ranges and probe lengths available the Model 340T/AI/AF/AN is adaptable for most temperature applications or processes. The compact size provides easy installation for on-board vehicles used in the oil and gas industry.
| Model: | 311 I, GI, AI |
| Range: | 0 to 5 thru 0 to 75K PSI (0 to 0.3 thru 0 to 5,171 BAR) *PSIG, PSIS, PSIA, PSIV & Compound Ranges Available |
| Certification: | FM, CSA ATEX, IEC Intrinsically Safe; For Explosion-proof see model 311X/P |
| Warranty: | Product Warranty |
GP:50’s Model 11 series provides a rugged solution in hazardous approved areas. The all welded, stainless steel design provides years of reliable service in some of the harshest applications.
Learn More
| Model: | 311-IM |
| Range: | 0 to 50 PSI thru 0 to 750 PSI (0 to 3 thru 0 to 50 BAR) *Some Options May Affect Range *PSIG, PSIS, PSIA, PSIV Compound Ranges Available |
| Warranty: | Product Warranty |
The Model 311-IM from GP:50 is a flush mounted, hazardous location approved pressure transducer, designed to provide added reliability within slurry or thick process media applications. Their rugged, all-welded flush mounted design facilitates accurate measurements of corrosive or higher viscosity media, in applications where non-flush port sensors are otherwise
prone to clogging or damage. No zero offset is caused during sensor installation.
| Range: | 0 to 20K thru 0 to 100K PSI (1,079 thru 6,895 BAR) |
| Warranty: | Product Warranty |
Model 112/212/312 from GP:50 is an ultra high-pressure transducer, offered in a single piece sensor design with no welds or seals. All stainless steel construction and industry standard highpressure coned process connections are available in both English and Metric sizes.
Learn More
| Model: | Model 211/311 HD-QX & 240/340 HD-QX | Cryogenic & High Temperature Pressure Transducer |
| Range: | Cryogenic Ranges: 50 PSI thru 6K PSIG (3.5 thru 345 BAR) High Temperature Ranges: 150 PSI thru 15K PSIG *Sealed Gauge or Absolute Formats |
| Certification: | ATEX, CSA Approvals |
| Warranty: | Product Warranty |
The Model 211/311 HD-QX & 240/340 HD-QX Series from GP:50 offer reliable pressure sensing in cryogenic or high temperature applications.
Remote mounted electronics provide a highlevel 4-20 mA or 0-5 Vdc output with optional CANbus, RS485 Modbus, USB or RS232 digital protocols. The SST, armor jacketed cable provides flexibility in mounting the electronics away from the process temperature. 18”-36” remote flex lengths are available.
| Model: | Series 400, 500, 600, 700, 800, 900 |
| Range: | Varies by Series |
| Warranty: | Product Warranty |
GP:50’s line of Digital output Pressure, Level and Temperature Transmitters is among the most extensive available in the marketplace.
Our Engineering team continues to lead the industry with innovative pressure and temperature measurement options including USB, and SDI-12 transmitters as well other well-established digital protocols such as CAN bus and HART. These digital protocols can be provided on most of our current line of analog output pressure and temperature transducers.
