Shop GP:50

High Accuracy

  • Model 241/341| High Accuracy Pressure Transducer

    Model: 241/341 (AERO)
    Range: 0-30” WC thru 8K PSI (552 BAR) *Gauge, Vacuum, Absolute, Sealed Gauge (Both Hermetic & Non-Hermetic)
    Warranty: Product Warranty

    Tightest Thermal Stability in its class

    Model 241/341 from GP:50 is our most accurate pressure transducer. Designed specifically for aerospace and automotive test stand applications, it is 5x tighter through temperature than standard industrial transmitters with a 0.20% FSO / 100 °F thermal stability. More than 25 years of field expertise went into the design of our pressure transducer for exceptional reliability. The compact, corrosion-resistant, all-welded stainless steel design of the Model 241/341 offers ease of installation within space constrained environments. Static accuracy is available to ±0.05% FSO, with a total thermal error of 0.25% FSO over the compensated temperature range.

    Learn More

  • Model 541 | High Accuracy CANbus Transducer

    Model: 541
    Range: 0 to 1 thru 0 to 10,000 PSI (0.069 thru 690 BAR) *Gauge, Sealed, Absolute
    Warranty: Product Warranty

    The Model 541 series is our most accurate CAN based pressure transducer. Designed specifically for test stand applications, the CAN Bus protocol provides high resolution, reduced noise and improved thermal performance. The compact, all-welded stainless steel design of the Model 541 offers ease of installation within space constrained environments. Static accuracy is available to ±0.05% FSO, with a total thermal error of 0.25% FSO over the compensated temperature range.

    Learn More

  • Model 741 | High-Accuracy Digital Pressure Transducer

    Model: 741
    Range: 0 to 1 thru 0 to 8,000 PSI (0.069 thru 552 BAR) *Gauge, Sealed Gauge, Absolute
    Warranty: Product Warranty

    GP:50 Model 741 provides RS485 digital data transmission used in serial communication protocols standard for Industrial Control Networks and Data Acquisition Systems. High static accuracy, thermal performance and lack of EMI makes the 741 ideal for the auto and aircraft manufacturing floor.

    Learn More

  • Model 136/236/336 | Compact High-Accuracy Differential Pressure Transducer

    Model: 136/236/336
    Range: 1 PSID thru 500 PSID (0.1 thru 25 BAR D) *Other Ranges Available
    Warranty: Product Warranty

    The Model 136/236/336 from GP:50 is a family of highly accurate, digitally compensated differential pressure transducers. Model 136/236/336 measures differential pressure ranges as low as 20” WCD and line pressures up to 1000 PSID (69 BAR) in a compact size. Customers may also choose from among multiple accuracy, digital output, process and electrical connections. Please consult the factory for details.

    Learn More

  • Model 216/316 | Low Range High Line Differential Pressure Transducer

    Model: 216/316
    Range: 2.5” WCD thru 200 PSID *Alternate Ranges Available
    Warranty: Product Warranty

    The Model 216/316 from GP:50 is a family of low range, high line,  differential pressure transducers. Their compact design incorporates GP:50’s own digital correction circuit technology, for high accuracy and extended service life across a variety of applications.



    Learn More

  • Model 8200 | Flight Heritage Digitally Corrected Pressure Transducer

    Model: 8200
    Range: 0-1 PSIG, 0-3 PSIA thru 0-7500 PSI max options (69 mBAR thru 517 BAR)
    Warranty: Product Warranty

    The Model 8200 series from GP:50 is a flight heritage, high level pressure transducer. Digitally corrected to provide high-accuracy pressure measurements with a proprietary sensor design for added zero stability for commercial aviation, military, aerospace, UAV, satellite, and defense
    applications.

    Learn More

  • Model 8300 | Flight Heritage Digitally Corrected Differential Pressure Transducer

    Model: 8300
    Range: 0 to 1 thru 0 to 500 PSID (0.07 Bar thru 34.5 BAR) Bi-directional or uni-directional
    Warranty: Product Warranty

    The Model 8300 series from GP:50 is a flight heritage, differential pressure transducer, providing high reliability with high accuracy. The compact, proprietary sensor design provides years of reliable measurement required for commercial aviation, military, aerospace, UAV, satellite, and defense applications.

    Learn More

  • Model 136/236/336-AI/AF | Compact High-Accuracy Differential Pressure Transducer

    Model: 136/236/336-AI/AF
    Range: 1 PSID thru 500 PSID (0.1 thru 25 BAR D) *Other Ranges Available
    Certification: ATEX/IEC Intrinsically Safe; ATEX/IEC Flameproof
    Warranty: Product Warranty

    The Model 136/236/336-AI/AF from GP:50 is a family of highly accurate, digitally compensated differential pressure transducers. Model 136/236/336-AI/AF measures differential pressure ranges as low as 20” WCD and line pressures up to 1000 PSID (69 BAR) in a compact size. Customers may also choose from among multiple accuracy, digital output, process and electrical connections. Please consult the factory for details.

    Learn More
