| Model: | 114/214/314 (Differential Pressure) |
| Range: | 500 PSID to 20K PSID (25 BAR D to 1,379 BAR D) |
|
Warranty: | Product Warranty |
Model 114/214/314 Ultra High Range Differential Pressure Transducer series from GP:50 offers +0.50% (BFSL) static accuracy over its standard ranges of 500 to 20K PSID (35 to 1,379 BAR D). Improved accuracy is available to +0.20%. Their rugged, compact design incorporates a unique, non-filled strain gauge sensing technology. These attributes allow the Model 114/214/314 to effectively support high-cycle pressure measurement requirements, even in space constrained environments. An all stainless steel construction, without seals or o-rings, provides high-corrosion resistance. Optional intrinsically safe versions are also available for extreme applications.
Learn More
| Model: | 142 / 242 / 342 (Industrial) |
| Range: | 0 to 15 thru 0 to 15K PSI (1 thru 1,034 BAR) |
|
Warranty: | Product Warranty |
Model 142/242/342 Vehicle Test Pressure Transducer / Transmitter developed from 20+ years of aerospace experience, the 42 Series was designed with aerospace criteria for industrial applications. The compact all-welded construction offers higher accuracies and a broad thermally compensated range. The 42 Series has all the performance and durability of an aerospace grade unit, but with industrial grade pricing.
Learn More
| Model: | 240/340 AI/AN/AF (Industrial) |
| Range: | 0 to 1 PSI thru 0 to 50K PSI *Some Options May Affect Range PSIG, PSIS PSIA, PSIV & Compound Ranges Available |
| Certification: | ATEX & IEC Approvals |
|
Warranty: | Product Warranty |
Model 40 Hazardous Locations Pressure Transmitter Series from GP:50 incorporates over 25 years of oil field proven design in a 1” diameter package. The 40 Series provides a rugged solution for hazardous approved areas, especially where space constraints are a concern. Its all-welded stainless steel design will provide years of reliable service in some of the harshest environments.
Learn More
| Model: | 1002/1003-CA (Industrial) |
| Range: | 0 to 15 thru 0 to 10K PSI (1,034 mBAR thru 689 BAR), gauge, vacuum, and absolute pressure reference available |
| Certification: | CE |
|
Warranty: | Product Warranty |
Model 1002/1003-CA Low-Cost OEM Pressure Transducer from GP:50 is a family of lower cost, industrial grade OEM pressure transducers, featuring corrosion-resistant, all stainless steel wetted parts and housings. Series transducers are ideal for higher volume pressure monitoring applications, particularly where lower costs are required, yet where the need for precision measurement accuracy remains. Units are available with choice of 4-20 mA, 0 to 5 Vdc or 0 to 10 Vdc output, as well as various electrical connection and pressure port options. Typical applications for the Model 1002/1003-CA include off-road vehicle, HVAC/R, hydraulic and pneumatic control systems, pumps and compressors, and industrial engine pressure monitoring.
Learn More
