Cryogenic / High Temperature

  • Model 7790 | High Temperature Pressure and Temperature Transducer

    Model: 7790 (AERO)
    Range: 0 to 300 thru 0 to 15K PSIA, PSIG, or PSISG Options (20 thru 1,034 BAR)
    Warranty: Product Warranty

    Model 7790 High Temperature Pressure and Temperature transducer series from GP:50 provides pressure and temperature measurement up to +350 °F (+177 °C). The remote electronics provides a high level output of 4-20 mA or 0 to 5 Vdc while reducing the overall footprint by integrating pressure and temperature measurement in one device.

    Learn More

  • Model 7780 | High Temperature Pressure Transducer

    Model: 7780 (AERO)
    Range: 0 to 300 thru 0 to 15K *PSIA, PSIG, or PSISG Options (20 thru 1,034 BAR)
    Warranty: Product Warranty

    Model 7780 High Temperature Pressure Transducer Series from GP:50  offers consistent measurement accuracy in temperatures up to +350 °F (+177 °C). The Series features a lightweight, all stainless steel construction with choice of either 4-20 mA, 0 to 5 Vdc, or 0 to 10 Vdc  output; or optional digital protocols. Onboard isolated transducer electronics are remotely mounted via stainless steel armor jacketed flex tubing. The high-reliability of the Model 7780 Series is field-proven over 25 years and hundreds of applications, including higher shock and vibration environments.

    Learn More

  • Model 7770 | Extreme High-Temperature Transmitter

    Model: 7770 (AERO)
    Range: SYSTEM PRESSURE: Up to 2000 PSI (138 BAR), Optional 10K PSI (689 BAR) TEMP RANGES: +70°F to +500°F (+20°C to +260°C)
    Warranty: Product Warranty

    Model 7770 Extreme High-Temperature Transmitter Series from GP:50  offers consistent measurement accuracy in temperatures up to +500 °F (+260 °C). Their lightweight, all stainless steel construction incorporates on-board isolated electronics, which are remotely mounted via stainless steel armor jacketed flex tubing. The onboard electronics are designed to offer a highlevel 4-20 mA, 0 to 5 Vdc, or 0 to 10 Vdc output. Direct transducer mounting can also provide greater process media measurement accuracy. The highreliability of the Model 7770 Series has been fieldproven over 25 years and hundreds of applications.

    Learn More

  • Model 7730 | Dual Cryogenic Pressure Temperature Transducer

    Model: 7730 (AERO)
    Range: 0 to 300 thru 0 to 6K PSIA or PSIS options (21 thru 413 BAR) (Consult factory for ranges <300 or >6,000 PSIA, PSIS)
    Warranty: Product Warranty

    Model 7730 dual cryogenic pressure temperature transducer series from GP:50 provides pressure and temperature measurement in one device down to -320 °F (-196 °C). The remote mounted
    electronics offers a high level output of 4-20 mA, 0 to 5 Vdc or various digital protocols at high accuracies. 100 or 1,000 Ω platinum RTD is available as well as dual analog outputs.

    Learn More

  • Model 7720 | Cryogenic Pressure Transducer

    Model: 7720 (AERO)
    Range: Ranges 0 to 300 thru 0 to 6K PSI or PSISG (20 thru 413 BAR)
    Warranty: Product Warranty

    Model 7720 cryogenic pressure transducer from GP:50 offers consistent measurement accuracy in temperatures as low as -320 °F (-196 °C). The Series features a lightweight, all stainless steel construction with choice of either 4-20 mA, 0 to 5 Vdc, or 0 to 10 Vdc output; or optional digital protocols. Onboard isolated transducer electronics are remotely mounted via stainless steel armor jacketed flex tubing. The high-reliability of the Model 7720 Series has been successfully field-proven over 25 years and hundreds of critical applications.

    Learn More

  • Model 7710 | Cryogenic Temperature Transducer

    Model: 7710 (AERO)
    Range: Designed for up to 2000 PSI (138 BAR) higher system pressures also available
    Warranty: Product Warranty

    Model 7710 cryogenic temperature transducer from GP:50 is designed to provide high-reliability low-temperature measurements to -320°F (-196 °C) within a rugged, all-stainless steel package. Remotely mounted electronics provide a high-level signal output of either 4-20 mA; 0 to 5 Vdc; or 0 to 10 Vdc, as well as choice of RS232 or RS485 for improved cryogenic measurement accuracy and higher resolution. Stainless steel
    armor jacketed cabling provides added protection from extreme environmental conditions.

    Learn More

  • Model 211/311 HD/QX and 240/340 HD/QX | Cryogenic & High Temperature Pressure Transducer

    Model: 211/311 HD-QX & 240/340 HD-QX (Industrial)
    Range:

    Cryogenic Ranges: 50 PSI thru 6K PSIG (3.5 thru 345 BAR)

    High Temperature Ranges: 150 PSI thru 15K PSIG
    (10 thru 1,020 BAR)

    *Sealed Gauge or Absolute Formats

    Certification: ATEX, CSA Approvals
    Warranty: Product Warranty

    Model 211/311 HD/QX and 240/340 HD/QX Series from GP:50 offer  reliable pressure sensing in cryogenic or high temperature applications.
    Remote mounted electronics provide a highlevel 4-20 mA or 0-5 Vdc output with optional CANbus, RS485 Modbus, USB or RS232 digital protocols. The SST, armor jacketed cable provides flexibility in mounting the electronics away from the process temperature. 18”-36” remote flex lengths are available.

    Learn More

  • Model 170QX/270QX/370QX | High Pressure High Temperature Pressure Transducer

    Model: 170QX 270QX 370QX (Oil & Gas)
    Range: 0 to 1000 PSI thru 0 to 20K PSI (69 thru 1,379 BAR)
    Certification:

    FM/CSA/ATEX/IEC Intrinsic Safety

    FM/CSA/ATEX/IEC Zone

    CE Marked

    Warranty: Product Warranty

    Model 170QX/270QX/370QX High Pressure High Temperature Pressure Transducer series from GP:50 is designed for High Pressure High Temperature (HPHT) well applications. This series is designed to fit the standard WECO® 2”- 1502 or 2”- 2002/2202 unions and operates at
    a continuous process temperature to +350 °F (+177 °C). It offers reliable service in high shock and vibration applications such as cementing, fracturing and drilling mud pressure measurement.

    Learn More
