| Model: | 541 (Industrial) |
| Range: | 0 to 1 thru 0 to 10,000 PSI (0.069 thru 690 BAR) *Gauge, Sealed, Absolute |
| Warranty: | Product Warranty |
The Model 541 series is our most accurate CAN based pressure transducer. Designed specifically for test stand applications, the CAN Bus protocol provides high resolution, reduced noise and improved thermal performance. The compact, all-welded stainless steel design of the Model 541 offers ease of installation within space constrained environments. Static accuracy is available to ±0.05% FSO, with a total thermal error of 0.25% FSO over the compensated temperature range.
Learn More
| Model: | 741 (Industrial) |
| Range: | 0 to 1 thru 0 to 8,000 PSI (0.069 thru 552 BAR) *Gauge, Sealed Gauge, Absolute |
| Warranty: | Product Warranty |
Model 741 High-Accuracy Digital Pressure Transducer provides RS485 digital data transmission used in serial communication protocols standard for Industrial Control Networks and Data Acquisition Systems. High static accuracy, thermal performance and lack of EMI makes the 741 ideal for the auto and aircraft manufacturing floor.
Learn More
| Model: | 411/411XP (Oil & Gas) |
| Range: | 0-15 PSI thru 0-100K PSI (0-1 thru 6,895 BAR) |
| Certification: | HART Protocol, CSA & FM Approvals |
| Warranty: | Product Warranty |
Model 411/411XP Smart Rangeable Hazardous Location Pressure Transmitter from GP:50 incorporates a 4-20 mA output with digital HART protocol. Units are offered with both CSA and FM approval options, as well as a variety of process and electrical connections. Improved accuracy provides for a stable measurement throughout the total compensated temperature range.
Learn More
| Model: | 540 (Industrial) |
| Range: | 0-1 PSI thru 0-10K PSI (3.5 mBAR to 344 BAR) *Gauge, Sealed Gauge, Absolute |
| Warranty: | Product Warranty |
Model 540 CANbus Digital Output Pressure Transducer provides high resolution, accuracy, and improved thermal performance to meet the demands of the automotive, medical and laboratory test markets. The CAN Open protocol allows for multiple devices on a single bus reducing installation time and cost.
Learn More
| Model: | 540-IM (Oil & Gas) |
| Range: | 0 to 50 thru 0 to 1000 PSI (3.5 thru 69 BAR) Gauge, Sealed Gauge, Absolute |
| Warranty: | Product Warranty |
Model 540-IM Flush Mount CANbus Pressure Transmitter series from GP:50 offers CAN Bus protocol in a flush faced sensor design. GP:50’s CAN Bus protocol provides high resolution, reduced noise and improved thermal performance. The flush Inconel diaphragm provides maximum corrosion resistance and limits plugging associated with viscous media.
| Model: | 611/612 (Industrial) |
| Range: | • (Model 611) 0 to 1 thru 0 to 15K PSIG (0-0.069 thru 0-1,034 BAR) • (Model 612) 0 to 20k thru 0 to 100K PSIG ( 0-1,379 thru 0-6,895 BAR) |
| Warranty: | Product Warranty |
USB Drivers & GP:50 Data Logging Software 1/2024
Model 611/612 USB Output Pressure Transducer from GP:50 is a USB output pressure transducer. This model features an intuitive and user-friendly interface that allows for field configuration. For customer convenience, an easy-to-use data acquisition and analysis software is available and fully compatible with any Windows-based terminal program.
Learn More
| Model: | 913 |
| Range: | 0-30" WC to 0-700 feet WC (762 mm to 213.4 meters WC) |
| Warranty: | Product Warranty |
The Model 913 from GP:50 is a high-accuracy submersible level transmitter. It features an asynchronous serial communication output (SDI-12-v 1.3), typically used to monitor environmental data. This also allows for communication with compatible data loggers or data acquisition
systems. The incorporation of a hydrophobic breather vent ensures extended trouble-free service within demanding applications. These features, combined with the low power requirements of the Model 913, make it particularly ideal for remote well monitoring applications.
| Model: | Series 400, 500, 600, 700, 800, 900 |
| Range: | Varies by Series |
| Warranty: | Product Warranty |
GP:50’s line of Digital output Pressure, Level and Temperature Transmitters is among the most extensive available in the marketplace.
Our Engineering team continues to lead the industry with innovative pressure and temperature measurement options including USB, and SDI-12 transmitters as well other well-established digital protocols such as CAN bus and HART. These digital protocols can be provided on most of our current line of analog output pressure and temperature transducers.
