Model 115/215/315 High Range Differential Pressure Transducer

Model 115/215/315 | High Range Differential Pressure Transducer

Download Datasheet Request Quote
Product Specs
Model: 115/215/315 (Differential Pressure)
Range: 30 PSID (2 BAR D) to 7,500 PSID (317 BAR D)
Certification:

Optional FM & CSA Explosion-Proof Approval

Optional FM, CSA, or ATEX Intrinsically Safe Approval

Warranty: Product Warranty

Model 115/215/315 High Range Differential Pressure Transducer from GP:50 is a family of compact, high-range differential pressure transducers. Series units are offered in ranges as low as 0 to 30 PSID (0 to 2 BAR D), with a line pressure range to 10K PSI (690 BAR). Their all-welded, corrosion-resistant, 316L stainless steel construction is without seals or o-rings, helping to ensure their continued reliability within demanding environments. Optional FM, CSA, ATEX intrinsic safety approvals are also available.

Categories: , Tags: , , ,

Description

Model 115/215/315 High Range Differential Pressure Transducer from GP:50 is a family of compact, high-range differential pressure transducers. Series units are offered in ranges as low as 0 to 30 PSID (0 to 2 BAR D), with a line pressure range to 10K PSI (690 BAR). Their all-welded, corrosion-resistant, 316L stainless steel construction is without seals or o-rings, helping to ensure their continued reliability within demanding environments. Optional FM, CSA, ATEX intrinsic safety approvals are also available.

Additional information

Markets

Pressure Ranges
